High power Submersible Ultrasonic transducer 28khz/40khz

2018-10-07 14:34 admin
High power Submersible Ultrasonic cleaner:

1. Clean the material, size and requirement of the workpiece, determine the transducer frequency and installation mode of the vibrating plate.

2, determine the size of the cleaning tank to determine the size of the ultrasonic plate, that is, the length and width.

3, determine the material and thickness of ultrasonic vibration plate, use 304 stainless steel or 316 titanium plate.

4. Determine the thickness and process of stainless steel material, including plating, according to the service life and production cost of customers.

5. According to the requirements of flume and process, the ultrasonic vibration plate fixing mode and outlet mode are determined.

6. According to the size of ultrasonic vibration plate, the power of ultrasonic vibration plate and the number of transducers are determined.

7, determine the delivery cycle according to the order and quantity of the process.
Type Diamention(mm) Frequency (Khz) Power(W) Ultrasonic Transducer
UCE-UITP300W 300*190*100 25,28,33,40,80,130 300 6
UCE-UITP600W 360*275*100 25,28,33,40,80,130 600 12
UCE-UITP1000W 450*350*100 25,28,33,40,80,130 1000 20
UCE-UITP1200W 470*380*100 25,28,33,40,80,130 1200 24
UCE-UITP1500W 520*450*100 25,28,33,40,80,130 1500 30
UCE-UITP1800W 560*450*100 25,28,33,40,80,130 1800 36
UCE-UITP2000W 650*450*100 25,28,33,40,80,130 2000 40
UCE-UITP2400W 740*520*100 25,28,33,40,80,130 2400 48
UCE-UITP3000W 820*540*100 25,28,33,40,80,130 3000 60
UCE-UITP5000W 1200*590*100 25,28,33,40,80,130 5000 100
OEM Ultrasonic Immersible Transducer Pack(Size, Frequency,Power)
High power Submersible Ultrasonic transducer 28khz/40khz

High power Submersible Ultrasonic transducer 28khz/40khz
