Industrial grade ultrasonic vibration plate / shock plate
When the trough-type Submersible
ultrasonic cleaner is not suitable for specific work needs, the ultrasonic vibration plate is not only suitable for self-built cleaning trough or existing cleaning trough with ultrasonic function, but also suitable for the maintenance and replacement of existing ultrasonic cleaning equipment, suitable for large
ultrasonic cleaning machine system with ultrasonic, but also suitable for ultrasonic extraction. Equipment and ultrasonic sewage treatment equipment are equipped with ultrasonic waves.
It can be installed in the cleaning tank (top, side and bottom) flexibly to achieve different cleaning effects.
Ultrasonic vibration board (shock plate) is mainly customized according to user needs and actual working conditions.
Characteristic:
A.SUS304/SUS316L/ and other titanium plate strong corrosion resistant stainless steel plate waterproof packaging welding.
The B. radiation surface can be plated with hard chromium to increase hardness and air defense corrosion.
C. high Q PZT transducer, stable and strong ultrasonic power.
The E. generator is connected with the shock plate by the optical fiber high frequency shielding wire to prevent skin effect.
F. According to customer requirements to order special specifications, different sizes, power, frequency (20KHZ-200KHZ,) non-standard equipment.
G. Different control modes can be realized according to customers'requirements (such as ordinary switch control, PLC weak current control, closed control, remote control, etc.).
Industrial grade ultrasonic vibration plate / shock plate
Type |
Diamention(mm) |
Frequency (Khz) |
Power(W) |
Ultrasonic Transducer |
UCE-UITP300W |
300*190*100 |
25,28,33,40,80,130 |
300 |
6 |
UCE-UITP600W |
360*275*100 |
25,28,33,40,80,130 |
600 |
12 |
UCE-UITP1000W |
450*350*100 |
25,28,33,40,80,130 |
1000 |
20 |
UCE-UITP1200W |
470*380*100 |
25,28,33,40,80,130 |
1200 |
24 |
UCE-UITP1500W |
520*450*100 |
25,28,33,40,80,130 |
1500 |
30 |
UCE-UITP1800W |
560*450*100 |
25,28,33,40,80,130 |
1800 |
36 |
UCE-UITP2000W |
650*450*100 |
25,28,33,40,80,130 |
2000 |
40 |
UCE-UITP2400W |
740*520*100 |
25,28,33,40,80,130 |
2400 |
48 |
UCE-UITP3000W |
820*540*100 |
25,28,33,40,80,130 |
3000 |
60 |
UCE-UITP5000W |
1200*590*100 |
25,28,33,40,80,130 |
5000 |
100 |
OEM Ultrasonic Immersible Transducer Pack(Size, Frequency,Power) |
