Submersible ultrasonic transducer with cleaning tank

2018-10-07 14:43 admin
Submersible ultrasonic cleaner,The input ultrasonic vibrating plate (vibrating plate) consists of two parts: the ultrasonic transducer is glued to the fully sealed stainless steel vibrating box and the ultrasonic generator.
When the trough type ultrasonic cleaning equipment is not suitable for specific work needs, the ultrasonic vibration plate is not only suitable for self-built cleaning trough or existing cleaning trough to install ultrasonic cleaning function, but also suitable for the existing ultrasonic cleaning equipment to repair and replace the ultrasonic vibration plate, suitable for large ultrasonic cleaning machine system to install ultrasonic vibration plate, and at the same time. It is also suitable for ultrasonic extraction equipment and ultrasonic sewage treatment equipment equipped with ultrasonic waves.
Ultrasonic vibration plate can be flexibly installed in different parts of the cleaning tank (top, side, bottom) to achieve different cleaning effect.
Ultrasonic vibration plate 28khz/40khz
Type Diamention(mm) Frequency (Khz) Power(W) Ultrasonic Transducer
UCE-UITP300W 300*190*100 25,28,33,40,80,130 300 6
UCE-UITP600W 360*275*100 25,28,33,40,80,130 600 12
UCE-UITP1000W 450*350*100 25,28,33,40,80,130 1000 20
UCE-UITP1200W 470*380*100 25,28,33,40,80,130 1200 24
UCE-UITP1500W 520*450*100 25,28,33,40,80,130 1500 30
UCE-UITP1800W 560*450*100 25,28,33,40,80,130 1800 36
UCE-UITP2000W 650*450*100 25,28,33,40,80,130 2000 40
UCE-UITP2400W 740*520*100 25,28,33,40,80,130 2400 48
UCE-UITP3000W 820*540*100 25,28,33,40,80,130 3000 60
UCE-UITP5000W 1200*590*100 25,28,33,40,80,130 5000 100
OEM Ultrasonic Immersible Transducer Pack(Size, Frequency,Power)
Submersible ultrasonic transducer with cleaning tank

Submersible ultrasonic transducer with cleaning tank
