Ultrasonic cleaning of
ultrasonic cleaning machine belongs to physical cleaning, which itself is green cleaning, if the appropriate cleaning agent is added to the cleaning solution is a combination of cleaning, more obvious cleaning effect. Ultrasonic cleaning is widely used in power ultrasonic cleaning, which is closely related to the development of modern science and technology and advanced manufacturing technology. Ultrasound cleaning is one of the most effective chemical, physical and mechanical cleaning methods. It is widely used in machinery, optics, electronics, light industry, textile, chemical industry, shipping, atomic energy, medical and other industrial sectors. Ultrasound cleaning equipment makes use of the socialization, acceleration and direct inflow of ultrasound in liquid to clean liquid and dirt directly and indirectly, so that the dirt layer is dispersed, emulsified and peeled off. In the ultrasonic cleaning machine used for ultrasonic cleaning, cavitation and direct flow are applied more. Compared with other cleaning methods, ultrasonic cleaning has the advantages of high cleaning rate, less residue, short cleaning time and good cleaning effect. Ultrasound cleaning can be used to clean the cleaned parts which can be soaked in liquid. It is not restricted by the surface shape of the cleaning parts, such as deep holes, slits, and grooves. Can be cleaned. Because the
ultrasonic generator uses D type amplification, the transducer has high electro-acoustic efficiency, so the ultrasonic cleaning has high efficiency and energy saving. It is a truly high-speed, high quality, easy to achieve automatic cleaning technology. If the cleaning agent uses non ODS cleaning agent, it has the function of green environmental protection. Ultrasonic cleaning has a good cleaning effect on reflective objects such as glass and metal, but it is not suitable for materials with strong sound absorption such as textiles, porous foam plastics and rubber products. Compared with various chemical, physical, electrochemical and ultrasonic cleaning methods, ultrasonic cleaning has the following unique advantages: it can quickly and thoroughly remove all kinds of dirt on the surface of the workpiece. It can clean complicated parts with cavity and groove. No damage to workpiece surface. Various cleaning agents can be used. Cleaning at room temperature or proper heating (around 60 C).
Type |
Internal size
L*W*H (mm) |
Frequency (Khz) |
Power(W) |
Heating(W) |
UCE-1006ST |
280×210×210 |
20,28,33,40,80,130 |
300 |
1000 |
UCE-1012ST |
400×310×280 |
20,28,33,40,80,130 |
600 |
3000 |
UCE-1018ST |
490×360×320 |
20,28,33,40,80,130 |
900 |
3000 |
UCE-1024ST |
630×430×320 |
20,28,33,40,80,130 |
1200 |
4000 |
UCE-1030ST |
630×530×320 |
20,28,33,40,80,130 |
1500 |
4000 |
UCE-1036ST |
680×530×360 |
20,28,33,40,80,130 |
1800 |
5000 |
UCE-1040ST |
680×570×400 |
20,28,33,40,80,130 |
2000 |
5000 |
UCE-1041ST |
730×570×450 |
20,28,33,40,80,130 |
2400 |
6000 |
UCE-1042ST |
790×670×510 |
20,28,33,40,80,130 |
3000 |
6000 |
UCE-1043ST |
850×770×570 |
20,28,33,40,80,130 |
4000 |
7000 |
UCE-1044ST |
910×820×620 |
20,28,33,40,80,130 |
5000 |
7000 |
UCE-1045ST |
960×870×680 |
20,28,33,40,80,130 |
8000 |
8000 |
UCE-1046ST |
1100×930×730 |
20,28,33,40,80,130 |
10000 |
8000 |
