ultrasonic system for solar panel cleaning 40khz/80khz

This equipment is designed on the multi-slot ultrasonic technology of automatic line cleaning machine, according to customer needs, cleaning parts size and output and cleaning requirements, to provide personalized non-standard custom special ultrasonic cleaning line, PLC touch screen automatic control, can achieve cleaning, rinsing, cutting water, drying, throwing, spinning Cleaning and other functions.



The equipment has automatic and semi-automatic two ways, carbon steel skeleton, inside groove and outside groove are made of stainless steel.

Type	Internal size L*W*H (mm)	Frequency (Khz)	Power(W)	Heating(W)
UCE-1006ST	280×210×210	20,28,33,40,80,130	300	1000
UCE-1012ST	400×310×280	20,28,33,40,80,130	600	3000
UCE-1018ST	490×360×320	20,28,33,40,80,130	900	3000
UCE-1024ST	630×430×320	20,28,33,40,80,130	1200	4000
UCE-1030ST	630×530×320	20,28,33,40,80,130	1500	4000
UCE-1036ST	680×530×360	20,28,33,40,80,130	1800	5000
UCE-1040ST	680×570×400	20,28,33,40,80,130	2000	5000
UCE-1041ST	730×570×450	20,28,33,40,80,130	2400	6000
UCE-1042ST	790×670×510	20,28,33,40,80,130	3000	6000
UCE-1043ST	850×770×570	20,28,33,40,80,130	4000	7000
UCE-1044ST	910×820×620	20,28,33,40,80,130	5000	7000
UCE-1045ST	960×870×680	20,28,33,40,80,130	8000	8000
UCE-1046ST	1100×930×730	20,28,33,40,80,130	10000	8000
