ultrasonic piezo transducer cleaning for industry and household

ultrasonic piezo transducer cleaning for industry and household
Everyone knows that the interior of the shock plate is made up of ultrasonic transducers. When the frequency of the cleaning machine is very low (within the range of human hearing), it will produce noise. When the frequency is less than 20 kHz, the working noise not only becomes very high, but also may exceed the safety noise limit stipulated by the Occupational Safety and Health Act or other regulations. In applications requiring high power to remove dirt without considering workpiece surface damage, the lower frequency of cleaner is usually chosen from 20 kHz to 40 kHz. The cleaning frequency in this frequency range is often used to clean large, heavy parts or high density materials. The ultrasonic oscillator produced by Boda Ultrasound has fixed 28KHZ and 40KHZ low-frequency ultrasonic oscillators.

Type	Length（mm）	Weight（g）	Frequency（KHz）	Resonance Impedance （Ω）	Static Capacity （pF）±10%	Input Power（W）
UCE-UT-20100 PZT-8	94	900	20	10-20	5200	100
UCE-UT-25100 PZT-4	77	710	25	10-20	6600	100
UCE-UT-28120 PZT-4	66	720	28	10-20	7800	120
UCE-UT-28100 PZT-8	66	625	28	10-20	5200	100
UCE-UT-28100 PZT-4	66	624	28	10-20	6600	100
UCE-UT-30100 PZT-8	61	555	30	10-20	5200	100
UCE-UT-2560 PZT-4	77	530	25	10-20	5400	60
UCE-UT-2860 PZT-8	68	470	28	10-20	3800	60
UCE-UT-2850 PZT-4	82	425	28	10-20	4100	50
UCE-UT-3360 PZT-8	58	420	33	10-20	3800	60
UCE-UT-4060 PZT-8	55	300	40	10-20	3800	60
UCE-UT-4060 PZT-4	56	310	40	10-20	5400	60
UCE-UT-4050 PZT-4	54	260	40	10-20	4100	50
UCE-UT-4050-1 PZT-4	57	300	40	10-20	4100	50
UCE-UT-5435 PZT-4	36	135	54	10-20	3200	35
UCE-UT-6860 PZT-8	80	460	68	10-20	3800	60
UCE-UT-68120 PZT-4	67	588	68	10-20	7800	120
UCE-UT-8060 PZT-4	60	325	80	10-20	5400	60
UCE-UT-12060 PZT-4	56	260	120	10-20	5400	60
UCE-UT-13550 PZT-4	54	215	135	10-20	4200	50
