ultrasonic dishwasher sink Driving power supply

2019-05-26 11:50 admin
ultrasonic dishwasher sink Driving power supply
Because the ultrasonic dishwasher does not need motors, pumps, high-pressure water and circulating water, and the movement and rotation of the mechanism are not needed, everything is only completed by the quiet vibration of water molecules, so the noise of the machine is small, and the water is saved and the electricity is saved.

Because it uses the vibration of water molecule produced by ultrasonic wave to wash dishes, it does not need the rotating mechanism of spray arm and the impeller mechanism of traditional dishwasher, and it does not need pumps, motors and circulating water system, so the structure is much simpler, the chance of breakdown is much less, and the maintenance and after-sales service is simple.

Type

Power（W）

Frequency (KHz)

Transducer numbers

Size

AC110V60HZ+/-10%  USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

UCE-NT300

300W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

3-6

300x360x150

UCE-NT600

600W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

6-12

300x360x150

UCE-NT900

900W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

9-18

300x360x150

UCE-NT1000

1000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

10-20

300x360x150

UCE-NT1200

1200W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

12-24

300x360x150

UCE-NT1500

1500W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

15-30

300x360x150

UCE-NT1800

1800W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

18-36

300x360x150

UCE-NT2000

2000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

20-40

300x360x150

UCE-NT2400

2400W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

24-48

300x360x150

UCE-NT3000

3000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

50-60

300x360x150

High Frequency

300W-1200W

65-80khz

High Frequency

300W-1200W

120-135khz
Because the ultrasonic dishwasher does not need motors, pumps, high-pressure water and circulating water, and the movement and rotation of the mechanism are not needed, everything is only completed by the quiet vibration of water molecules, so the noise of the machine is small, and the water is saved and the electricity is saved. Because it uses the vibration of water molecule produced by ultrasonic wave to wash dishes, it does not need the rotating mechanism of spray arm and the impeller mechanism of traditional dishwasher, and it does not need pumps, motors and circulating water system, so the structure is much simpler, the chance of breakdown is much less, and the maintenance and after-sales service is simple.Because the ultrasonic dishwasher does not need motors, pumps, high-pressure water and circulating water, and the movement and rotation of the mechanism are not needed, everything is only completed by the quiet vibration of water molecules, so the noise of the machine is small, and the water is saved and the electricity is saved. Because it uses the vibration of water molecule produced by ultrasonic wave to wash dishes, it does not need the rotating mechanism of spray arm and the impeller mechanism of traditional dishwasher, and it does not need pumps, motors and circulating water system, so the structure is much simpler, the chance of breakdown is much less, and the maintenance and after-sales service is simple.
