Piezo ceramic (PZT) ring chip for industrial ultrasonic cleaner

Piezo ceramic (PZT) ring chip for industrial ultrasonic cleaner
Piezo ceramic (PZT) ring chip for industrial ultrasonic cleaner
Piezo ceramic vibrator made of material PZT-81 are used widely in ultrasonic cleaner, ultrasonic welding, ultrasonic distance measure sensor, ultrasonic detector, ultrasonic motor, ultrasonic transformer and other high-power emanant transducers because of the material’s ability of low dielectric loss under strong voltage and capability stabilization.
Piezo ceramic (PZT) ring chip for industrial ultrasonic cleaner

spec
Dimension
(mm)
Radial frequency
(
±5%)KHz
Capacitance
(
±12.5%)pF
Dielectric dissipation factor
tan
δ(%)
Impedance
(Ω)
Kr
Mechanical
quality factor
(Qm)
UCE-135322
Φ13×Φ5.3×2.2
126.8
455
≤0.3
≤15
≥0.55
500
UCE-1562
Φ15×Φ6×2
110.0
670
≤0.3
≤15
≥0.55
500
UCE-30105
Φ30×Φ10×5
51.0
1190
≤0.3
≤15
≥0.55
500
UCE-32115
Φ32×Φ11×5
47.2
1300
≤0.3
≤20
≥0.55
500
UCE-35155
Φ35×Φ15×5
45.9
1770
≤0.5
≤15
0.49
500
UCE-35155-1
Φ35×Φ15×5
45.5
1430
≤0.3
≤15
≥0.45
800
UCE-351555
Φ35×Φ15×5.5
45.9
1610
≤0.5
≤15
≥0.49
500
UCE-38165
Φ38×Φ16×5
42.0
2100
≤0.5
≤15
≥0.49
500
UCE-38165-1
Φ38×Φ16×5
42.0
1650
≤0.3
≤15
≥0.55
800
UCE-381364
Φ38×Φ13×6.4
44.1
1780
≤0.5
≤15
≥0.49
500
UCE-40155
Φ40×Φ15×5
42.8
1970
≤0.5
≤15
≥0.55
500
UCE-42155
Φ42×Φ15×5
40.0
1970
≤0.5
≤15
≥0.51
500
UCE-42175
Φ42×Φ17×5
38.8
2220
≤0.5
≤15
≥0.51
500
UCE-45155
Φ45×Φ15×5
37.7
3180
≤0.5
≤15
≥0.51
500
UCE-45155-1
Φ45×Φ15×5
38.1
2580
≤0.3
≤15
≥0.46
800
UCE-50175
Φ50×Φ17×5
34.8
3160
≤0.3
≤15
≥0.55
800
UCE-501765
Φ50×Φ17×6.5
34.8
3280
≤0.3
≤15
≥0.55
800
