Ultrasonic Vibrating Transducer 100W/33khz

Ultrasonic transducers are one of the important accessories on the ultrasonic sieving equipment...

WeChat

Ultrasonic transducers are one of the important accessories on the ultrasonic sieving equipment, and the primary role is to convert the electrical power into mechanical power and then to the vibrating screen (or other equipment), which consumes only a fraction of its power.
Ultrasonic transducer from the central piezoelectric ceramic components, before and after the metal cover, prestressed screws, electrode pads and insulation tube and other components. This kind of sandwich transducer (also known as: bolt fastening type transducer) produces stable ultrasonic waves when the load changes, which is the most basic and important method to obtain the power ultrasonic driving source.
Type Frequency(KHz) Input Power(W)
UCE-UVT-33 33KHZ 100W
UCE-UVT-35 35KHZ 100W

Ultrasonic Vibrating Transducer 50W/33khzUltrasonic Vibrating Transducer 50W/33khz

TAG ultrasonic: Ultrasonic Vibration Transducer Ultrasonic Vibrating Screen Transducer piezoelectric vibration transducer
