Application scope of ultrasonic Biodiesel Production Equipment for cleaning emulsion dispersing:
1. Biological industry: essential oil extraction, traditional Chinese medicine extraction, natural pigment extraction, polysaccharide extraction, flavonoid extraction, alkaloid extraction, polyphenol extraction, organic acid extraction, oil extraction.
2. Application of laboratory research institute: chemical stirring logistics stirring, cell smashing, product smashing, material dispersion (suspension preparation) and condensation.
3. Chemical industry: ultrasonic emulsification and homogenization, ultrasonic gel liquefaction, resin defoaming, ultrasonic demulsification of crude oil.
4. Ultrasonic biodiesel production: In various chemical production, the enhanced transesterification reaction and various chemical reactions are obviously accelerated.
5, water treatment industry: pollution, water quality degradation.
6, food and cosmetics industry: alcohol aging, cosmetic particles fine-grained, nanoparticles extraction.
7, graphene industry: graphene dispersion, graphene nanoparticles preparation.
8. In some landscape lakes and rivers: ultrasonic vibrator can also be used for algae killing and algae suppression.
|
Tubular Equipment
Type
|
Tubular Transducer
Type
|
Frequency
(KHz)
|
Ultrasound
Output(W)
|
Total Length
(mm)
|
Diameter
(mm)
|
Static Capacity
(pF±10%)
|
|
UCE-UE1
|
US-61
|
15-28
|
1000
|
500
|
Φ50-55
|
68000
|
|
UCE-UE5
|
US-25
|
15-28
|
1500
|
850
|
Φ50-55
|
68000
|
|
UCE-UE6
|
US-16
|
15-28
|
2000
|
1100
|
Φ50-55
|
132000
|
