28khz/40khz Label Cutting Ultrasonic Fabric Cutting Machine

2020-01-24 00:34 admin
28khz/40khz Label Cutting Ultrasonic Fabric Cutting Machine
Ultrasonic cutter, also known as ultrasonic cutter, is a kind of special ultrasonic equipment for cutting, and is one of the important categories of ultrasonic application. The principle of ultrasonic cutting is totally different from that of traditional cutting. Ultrasonic cutting is to use the energy of ultrasonic transducer to melt the local heating of the cut material, so as to achieve the purpose of cutting materials. Therefore, ultrasonic cutting does not need a sharp edge, and does not need a lot of pressure, which will not cause the edge collapse and damage of the material to be cut. At the same time, due to the ultrasonic vibration of the cutting knife, the friction resistance is very small, and the cut material is not easy to stick to the blade. It is especially effective for cutting viscous and elastic materials, frozen materials, such as food, rubber, etc., or objects that are inconvenient to be pressurized.
Type power
(W)
Frequency Welding time Contains
UCE-QG100W 100W 30khz,35khz,40khz 0.1-3sec generator , transducer ,horn,head
UCE-QG300W 300W 30khz,35khz,40khz 0.1-3sec generator , transducer ,horn,head
UCE-QG500W 500W 30khz,35khz,40khz 0.1-3sec generator , transducer ,horn,head
28khz/40khz Label Cutting Ultrasonic Fabric Cutting Machine
28khz/40khz Label Cutting Ultrasonic Fabric Cutting Machine

28khz/40khz Label Cutting Ultrasonic Fabric Cutting Machine
