The ultrasonic vibration plate device consists of two parts: shock plate and
ultrasonic generator. When the standard type of
ultrasonic cleaning machine is not suitable for a specific working environment, in addition to the special specifications of ultrasonic cleaning machine can be customized, can also be used to add the input vibration plate device. In the existing equipment, if there is a common cleaning tank, can be added to the shock plate device, converted into ultrasonic cleaning machine.
Features: All stainless steel SUS # 316 3.0T structure, through hard oxygen plating treatment, high insulation, acid and alkali resistance, beautiful and durable. Separate structure is adopted, high frequency wire with socket is used to connect the vibration plate and ultrasonic generator, which is convenient for use and maintenance.
Installation and layout are flexible. According to the need, the ultrasonic radiation surface is arranged on the bottom, side or top surface of the cleaning tank.
The ultrasonic cleaner equipped with ultrasonic generator has the following characteristics and functions:
He is a circuit board.
The output frequency of ultrasonic can be fine tuned according to different working conditions.
Ultrasonic swept line;
The ultrasonic output power is continuously adjustable with a range of 10-100%.
Application Industry:
Electronic industry, household appliances industry, toy industry, stationery industry, daily necessities industry, packaging industry, communications industry, automobile industry
Can be customized to various specifications, sizes, materials and other ultrasonic cleaning machine vibration plate, professional cast brand, worthy of trust!
Type |
Diamention(mm) |
Frequency (Khz) |
Power(W) |
Ultrasonic Transducer |
UCE-UITP300W |
300*190*100 |
25,28,33,40,80,130 |
300 |
6 |
UCE-UITP600W |
360*275*100 |
25,28,33,40,80,130 |
600 |
12 |
UCE-UITP1000W |
450*350*100 |
25,28,33,40,80,130 |
1000 |
20 |
UCE-UITP1200W |
470*380*100 |
25,28,33,40,80,130 |
1200 |
24 |
UCE-UITP1500W |
520*450*100 |
25,28,33,40,80,130 |
1500 |
30 |
UCE-UITP1800W |
560*450*100 |
25,28,33,40,80,130 |
1800 |
36 |
UCE-UITP2000W |
650*450*100 |
25,28,33,40,80,130 |
2000 |
40 |
UCE-UITP2400W |
740*520*100 |
25,28,33,40,80,130 |
2400 |
48 |
UCE-UITP3000W |
820*540*100 |
25,28,33,40,80,130 |
3000 |
60 |
UCE-UITP5000W |
1200*590*100 |
25,28,33,40,80,130 |
5000 |
100 |
OEM Ultrasonic Immersible Transducer Pack(Size, Frequency,Power) |
