Submersible Ultrasonic Transducer Plate 28khz/40khz

2018-10-07 14:56 admin
Submersible ultrasonic transducer product mix
1: stainless steel structure, acid and alkali resistant, beautiful and durable.
2: Separate structure, high frequency connection with socket between vibration plate and ultrasonic generator, easy to use and maintain.
3: The installation arrangement is flexible, according to different needs can be made into bottom shock type, side shock type and top shock type to adapt to different cleaning requirements.
4: ultrasonic vibration board advantage. Easy to maintain.
5: when the power of the trough type ultrasonic cleaning machine is too small, the input vibrating plate device can be used. For example, add the shock plate device in the existing cleaning tank, and turn it into an ultrasonic cleaner. It is also a low cost way.
Scope of application
Cleaning electroplated parts before plating cleaning, watch parts, hardware and machinery parts, polyester filter core, semiconductor silicon, tools, lenses, spectacles, jewelry, glassware, etc.
Type Diamention(mm) Frequency (Khz) Power(W) Ultrasonic Transducer
UCE-UITP300W 300*190*100 25,28,33,40,80,130 300 6
UCE-UITP600W 360*275*100 25,28,33,40,80,130 600 12
UCE-UITP1000W 450*350*100 25,28,33,40,80,130 1000 20
UCE-UITP1200W 470*380*100 25,28,33,40,80,130 1200 24
UCE-UITP1500W 520*450*100 25,28,33,40,80,130 1500 30
UCE-UITP1800W 560*450*100 25,28,33,40,80,130 1800 36
UCE-UITP2000W 650*450*100 25,28,33,40,80,130 2000 40
UCE-UITP2400W 740*520*100 25,28,33,40,80,130 2400 48
UCE-UITP3000W 820*540*100 25,28,33,40,80,130 3000 60
UCE-UITP5000W 1200*590*100 25,28,33,40,80,130 5000 100
OEM Ultrasonic Immersible Transducer Pack(Size, Frequency,Power)
