titanium alloy Submersible Ultrasonic Transducer

Can be customized according to customer requirements, by 2.5 thick 316 stainless steel tank, 24 sets of NTK ultrasonic transducer, ultrasonic generator. Trough body resistance to weak acid, weak alkali; Generator adopts high-performance digital anti-corrosion generator, SCM control has timing, over-current, over-voltage, over-heat protection function; Power adjustable, stable output; Unique sweep function, suitable for pre-plating surface treatment, plastic hardware, electronic circuit board, clock parts, glass, printing and dyeing The equipment is degreasing, wax removing and layer cleaning. The power output adopts the field effect transistor and IGBT module of American rectifier company. The stable output power is strong and durable.

Function description of high performance digital anticorrosive ultrasonic sounder

1, it has the functions of current, frequency, power display and setting off timer.

2, intelligent over current, over voltage and over temperature protection.

3. Unique pulse intermittent oscillation and frequency sweeping function, simulate the effect of water washing, cavitation effect is good, can carry on the omni-directional cleaning of the workpiece in the cleaning tank, and have a better cleaning effect on the complex workpiece and the workpiece with blind hole.

4. Adopting anti-corrosion and isolation treatment, it can adapt to harsh working environment, has unique soft-start function, overcomes the spike current, spike electric shock, is not easy to damage the power FET, and the output power is stable.

5. The power output adopts the high power FET of American rectifier company, and the output power is stable, strong and durable.

Type	Diamention(mm)	Frequency (Khz)	Power(W)	Ultrasonic Transducer
UCE-UITP300W	300*190*100	25,28,33,40,80,130	300	6
UCE-UITP600W	360*275*100	25,28,33,40,80,130	600	12
UCE-UITP1000W	450*350*100	25,28,33,40,80,130	1000	20
UCE-UITP1200W	470*380*100	25,28,33,40,80,130	1200	24
UCE-UITP1500W	520*450*100	25,28,33,40,80,130	1500	30
UCE-UITP1800W	560*450*100	25,28,33,40,80,130	1800	36
UCE-UITP2000W	650*450*100	25,28,33,40,80,130	2000	40
UCE-UITP2400W	740*520*100	25,28,33,40,80,130	2400	48
UCE-UITP3000W	820*540*100	25,28,33,40,80,130	3000	60
UCE-UITP5000W	1200*590*100	25,28,33,40,80,130	5000	100
OEM Ultrasonic Immersible Transducer Pack（Size, Frequency,Power）
