Ultrasonic cleaning machine vibrating plate / shock plate
Scope of application: pre-plating treatment, wax removal of watch case and watch strap, spectacle frame, glassware, metal stamping parts, mechanical parts, water heating devices, electronics, jewelry, clocks and watches, lighting and other industries product cleaning
Structure: the input ultrasonic vibration plate device consists of two parts: vibrating plate and
ultrasonic generator. Viscous ultrasonic vibrator: 36, ultrasonic power 1200W (power adjustable), frequency 28kHz, when the standard model of
ultrasonic cleaning machine is not suitable for a specific working environment, in addition to the special specifications can be customized, can also be used in the input shock plate device. In the existing equipment, if there is an ordinary cleaning tank, can be added to the vibrating plate device, converted into ultrasonic cleaning machine. All stainless steel structure, acid and alkali resistant, beautiful and durable. Separate structure is adopted, high frequency connection with socket is adopted between vibration plate and ultrasonic generator, which is convenient to use and maintain. The installation and layout are flexible, and the ultrasonic radiation surface can be arranged on the bottom, side and top surface of the cleaning tank as required.
_ultrasonic generator features: the use of microcomputer-controlled digital frequency synthesis technology, ultrasonic power continuously adjustable (digital display)
It has perfect protection function: overheating and overcurrent protection, and also has four-bit timer to make time control accurate to seconds.
At the same time, it also has the function of sweeping frequency.
Configuration: distribution of ultrasonic generator storage rack
Note: all kinds of non-standard sizes can be customized according to customer's requirements. If necessary, please contact them.
Foshan ultrasonic vibration plate manufacturers supply stamping parts, ultrasonic vibration board, input shock box.
Type |
Diamention(mm) |
Frequency (Khz) |
Power(W) |
Ultrasonic Transducer |
UCE-UITP300W |
300*190*100 |
25,28,33,40,80,130 |
300 |
6 |
UCE-UITP600W |
360*275*100 |
25,28,33,40,80,130 |
600 |
12 |
UCE-UITP1000W |
450*350*100 |
25,28,33,40,80,130 |
1000 |
20 |
UCE-UITP1200W |
470*380*100 |
25,28,33,40,80,130 |
1200 |
24 |
UCE-UITP1500W |
520*450*100 |
25,28,33,40,80,130 |
1500 |
30 |
UCE-UITP1800W |
560*450*100 |
25,28,33,40,80,130 |
1800 |
36 |
UCE-UITP2000W |
650*450*100 |
25,28,33,40,80,130 |
2000 |
40 |
UCE-UITP2400W |
740*520*100 |
25,28,33,40,80,130 |
2400 |
48 |
UCE-UITP3000W |
820*540*100 |
25,28,33,40,80,130 |
3000 |
60 |
UCE-UITP5000W |
1200*590*100 |
25,28,33,40,80,130 |
5000 |
100 |
OEM Ultrasonic Immersible Transducer Pack(Size, Frequency,Power) |
