It is mainly used for surface cleaning of all kinds of metal parts, such as unscented kerosene / waste oil / zinc chloride / Black welding mark. Hard substances attached to metal surface are treated by ultrasonic wave. According to the working principle of ultrasonic wave, the hard substances and oil stains on metal workpiece can be thoroughly cleaned after the attachment is separated from the metal surface and then washed by high pressure spraying. Thus, the cleaning degree can reach the ideal cleaning effect. Ultrasonic cleaning has the advantages of fast cleaning speed, good effect, no damage to objects, reducing labor intensity and saving cost.
Ultrasonic principle
Ultrasonic cleaning is based on the high-frequency ultrasonic oscillation signal generated by
ultrasonic generator, which is converted into mechanical oscillation and propagated to the medium cleaning solution (water, oil, solvent) to produce cavitation effect, resulting in hundreds of millions of vacuum bubble cycle "explosion" in the positive and negative pressure region of the medium. It is precisely this "implosion" impact force. At the same time, the workpiece also has a certain suction, so that the surface of the workpiece, cracks, holes and dirt peel off rapidly to achieve the goal of cleanliness. With the increase of
ultrasonic frequency, the number of bubbles increases and the impact of blasting decreases. Therefore, high-frequency ultrasound is especially suitable for cleaning small particles of dirt without breaking the surface of the workpiece.
Users need to know:
Users should provide detailed information of the cleaning workpiece, so that our company can carry out the relevant type selection and cleaning technology calculation.
2. Users should specify cleaning requirements, usage, cleaning quantity and so on.
Our company has a variety of types of single-slot, multi-slot, semi-automatic, automatic cleaning machine, input vibration plate, if the user specifies, will try to meet the requirements.
Type |
Internal size
L*W*H (mm) |
Frequency (Khz) |
Power(W) |
Heating(W) |
UCE-1006ST |
280×210×210 |
20,28,33,40,80,130 |
300 |
1000 |
UCE-1012ST |
400×310×280 |
20,28,33,40,80,130 |
600 |
3000 |
UCE-1018ST |
490×360×320 |
20,28,33,40,80,130 |
900 |
3000 |
UCE-1024ST |
630×430×320 |
20,28,33,40,80,130 |
1200 |
4000 |
UCE-1030ST |
630×530×320 |
20,28,33,40,80,130 |
1500 |
4000 |
UCE-1036ST |
680×530×360 |
20,28,33,40,80,130 |
1800 |
5000 |
UCE-1040ST |
680×570×400 |
20,28,33,40,80,130 |
2000 |
5000 |
UCE-1041ST |
730×570×450 |
20,28,33,40,80,130 |
2400 |
6000 |
UCE-1042ST |
790×670×510 |
20,28,33,40,80,130 |
3000 |
6000 |
UCE-1043ST |
850×770×570 |
20,28,33,40,80,130 |
4000 |
7000 |
UCE-1044ST |
910×820×620 |
20,28,33,40,80,130 |
5000 |
7000 |
UCE-1045ST |
960×870×680 |
20,28,33,40,80,130 |
8000 |
8000 |
UCE-1046ST |
1100×930×730 |
20,28,33,40,80,130 |
10000 |
8000 |
