Digital Ultrasonic Generator for cleaning tank

2019-05-21 10:19 admin
Digital Ultrasonic Generator for cleaning tank
With the latest excitation control circuit, the ultrasonic density has been greatly improved, the cleaning work is more meticulous and the cleanliness is higher. The ultrasonic power generator has the function of sweeping frequency. By sweeping the ultrasonic frequency in a reasonable range in the cleaning process, the cleaning liquid is driven to form a fine reflux, so that the workpiece dirt can be quickly removed from the workpiece surface while being stripped by ultrasound, and the cleaning efficiency can be improved. The original imported high-power transistor drives up to 95% of the power factor to ensure strong output power. For the dirt with strong adhesion ability, it can also be quickly removed. In the working state, real-time frequency tracking is realized. To ensure that the frequency of the ultrasonic transducer changes when the water temperature, the number of workpieces and the cleaning agent change, the ultrasonic generator can keep the automatic frequency chasing at any time to achieve the best working condition of matching the frequency of the transducer.

Unique function: In the working state, real-time frequency tracking function is realized. It ensures that when the frequency of the transducer changes under the conditions of water temperature, workpiece number, cleaning agent, etc., the generator can keep the automatic frequency chasing at any time to achieve the optimal working state matching the frequency of the transducer.

Shunting protection: during shunting process, set safe shunting current to ensure that no burning of pipes during shunting process.
Cleaning effect: The density of ultrasonic cleaning industry is the highest in China, the uniformity is the highest in China, and the dead angle of cleaning products is the highest.

Type

Power(W)

Frequency (KHz)

Transducer numbers

Size

AC110V60HZ+/-10%  USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

UCE-NT300

300W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

3-6

300x360x150

UCE-NT600

600W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

6-12

300x360x150

UCE-NT900

900W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

9-18

300x360x150

UCE-NT1000

1000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

10-20

300x360x150

UCE-NT1200

1200W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

12-24

300x360x150

UCE-NT1500

1500W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

15-30

300x360x150

UCE-NT1800

1800W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

18-36

300x360x150

UCE-NT2000

2000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

20-40

300x360x150

UCE-NT2400

2400W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

24-48

300x360x150

UCE-NT3000

3000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

50-60

300x360x150

High Frequency

300W-1200W

65-80khz

High Frequency

300W-1200W

120-135khz

Digital Ultrasonic Generator for cleaning tankDigital Ultrasonic Generator for cleaning tank

Digital Ultrasonic Generator for cleaning tank
