ultrasonic frequency generator box for cleaning

2019-05-20 13:15 admin

ultrasonic frequency generator box for cleaning

ultrasonic generator has all functions of 2012 digital display machine at the same time:

1. Using the technology of computer control and digital frequency synthesis, the frequency can be automatically tracked and adjusted.

2. Digital ultrasound power, continuous adjustable, more flexible and convenient to use;

3. Design a timing system with digital display and adjustable working time.

4. It has the function of sweeping frequency, the speed and width of sweeping frequency are adjusted digitally, and the steel plate is effectively protected.

5. Setting up PLC remote control interface to facilitate the connection with other control equipment;

6. Constant power output stabilization technology, not affected by voltage and load, protects equipment;

7. Full touch humanized key control, easy to debug and operate.

8. More efficient, more environmentally friendly, with more than 98% useful power output.

Type	Power（W）	Frequency (KHz)	Transducer numbers	Size
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE All of machine are available for opening remote control function to connect with your own PLC system
UCE-NT300	300W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	3-6	300x360x150
UCE-NT600	600W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	6-12	300x360x150
UCE-NT900	900W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	9-18	300x360x150
UCE-NT1000	1000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	10-20	300x360x150
UCE-NT1200	1200W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	12-24	300x360x150
UCE-NT1500	1500W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	15-30	300x360x150
UCE-NT1800	1800W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	18-36	300x360x150
UCE-NT2000	2000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	20-40	300x360x150
UCE-NT2400	2400W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	24-48	300x360x150
UCE-NT3000	3000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	50-60	300x360x150
High Frequency	300W-1200W	65-80khz
High Frequency	300W-1200W	120-135khz
