Double Frequency Ultrasonic Power Supply 40khz/100khz for cleaning

2019-05-25 11:57 admin
Double Frequency Ultrasonic Power Supply 40khz/100khz for cleaning
An important component of high-power ultrasonic system can also be called electronic box, ultrasonic driving power supply and ultrasonic controller. Although the ultrasonic generator can also be called the ultrasonic driving power supply, in fact, the ultrasonic generator is only a part of the ultrasonic driving power supply. Ultrasound power supply can be divided into self-excitation mode and other excitation mode according to the different excitation mode. Ultrasound generator refers to its excitation mode. Because its excitation oscillation circuit has more than 10% higher output power than the self-excitation mode, most of the current ultrasonic generators are used as driving power supply.

Ultrasound generator mainly adopts digital modular technology, which can meet the requirements of any precise cleaning. Whether connected with single groove, vibration plate or large cleaning system, it can provide fast, uniform and high quality cleaning effect.

Type

Power(W)

Frequency (KHz)

Transducer numbers

Size

AC110V60HZ+/-10%  USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

UCE-NT300

300W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

3-6

300x360x150

UCE-NT600

600W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

6-12

300x360x150

UCE-NT900

900W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

9-18

300x360x150

UCE-NT1000

1000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

10-20

300x360x150

UCE-NT1200

1200W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

12-24

300x360x150

UCE-NT1500

1500W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

15-30

300x360x150

UCE-NT1800

1800W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

18-36

300x360x150

UCE-NT2000

2000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

20-40

300x360x150

UCE-NT2400

2400W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

24-48

300x360x150

UCE-NT3000

3000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

50-60

300x360x150

High Frequency

300W-1200W

65-80khz

High Frequency

300W-1200W

120-135khz

Double Frequency Ultrasonic Power Supply 40khz/100khz for cleaningDouble Frequency Ultrasonic Power Supply 40khz/100khz for cleaning

Double Frequency Ultrasonic Power Supply 40khz/100khz for cleaning
