Koreanultrasonic generator of UCE ultrasonic
UCE ultrasound has developed a unique technology market, high-performance, high power, high frequency ultrasonic power supply (generator): automatic sweep, over power protection, overvoltage protection, overcurrent protection, undervoltage protection, over temperature protection, frequency tracking failure protection, output short circuit protection, power, powerful, stable performance.
Ultrasonic generator advantages, features the use of:
1.the NC was washed several times.
2.CNC digital ultrasonic power.
3.digital soft start, digital soft-off. Effective protection of the IGBT. And reduce the impact of the grid.
4.Output current ripple ≤ 2%, the cleaning effect is more stable oscillator can be well protected from damage.
5.Pure sine wave AC current.
6.Protection: power protection, overcurrent protection, overvoltage protection, undervoltage protection, the oscillator signal generator to protect and prolong the working life of the machine (you can play the role of isolation, when the oscillator is damaged, will not cause the same time generator of the damage, which in turn is the same reason, the occurrence of short circuit can automatically adapt to, and will not damage the machine).
|
Type |
Power（W） |
Frequency (KHz) |
|
UCE—UG300W |
300 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG500W |
500 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG600W |
600 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG900W |
900 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG1000W |
1000 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG1200W |
1200 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG1500W |
1500 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG1800W |
1800 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG2000W |
2000 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
UCE—UG2400W |
2400 |
20khz,25khz,28khz,33khz,40khz Frequency is adjustable |
|
High Frequency |
500W-1200W |
65-80 |
|
High Frequency |
500W-1200W |
120-135 |
