Submersible ultrasonic transducer and generator

Submersible ultrasonic cleaner with vibrating plate

The SUS316L stainless steel plate is made, and the vibrating surface is plated with 30 micron hard chromium. The advanced bonding technology in Europe can withstand harsh working conditions such as acid base and high temperature.

A variety of frequencies: 20, 25, 28, 40, 68, 87, 120, 130, 260, 400, 10000KHz.

The high frequency vibration plate is suitable for cleaning the precision parts and cleaning the blind holes below 1 millimeters.

The side vibration plate is suitable for cleaning rack parts and large workpieces.

The bottom vibration plate is suitable for cleaning small parts in washing basket and beaker.

Top-vibrating vibrator is suitable for cleaning circuit boards, glass substrates, aluminum substrates, magnetic cores and other cleaning lines which need to be cleaned on both sides.

Flange type vibrating plate is suitable for cleaning optical lens and other workpiece, reducing the dead angle and dirt in the groove.

Type	Diamention(mm)	Frequency (Khz)	Power(W)	Ultrasonic Transducer
UCE-UITP300W	300*190*100	25,28,33,40,80,130	300	6
UCE-UITP600W	360*275*100	25,28,33,40,80,130	600	12
UCE-UITP1000W	450*350*100	25,28,33,40,80,130	1000	20
UCE-UITP1200W	470*380*100	25,28,33,40,80,130	1200	24
UCE-UITP1500W	520*450*100	25,28,33,40,80,130	1500	30
UCE-UITP1800W	560*450*100	25,28,33,40,80,130	1800	36
UCE-UITP2000W	650*450*100	25,28,33,40,80,130	2000	40
UCE-UITP2400W	740*520*100	25,28,33,40,80,130	2400	48
UCE-UITP3000W	820*540*100	25,28,33,40,80,130	3000	60
UCE-UITP5000W	1200*590*100	25,28,33,40,80,130	5000	100
OEM Ultrasonic Immersible Transducer Pack（Size, Frequency,Power）
