ultrasonic cleaner and vibration plate are the most important parts of ultrasonic cleaning. They are ultrasonic transducers, which are welded and planted with screw and glued with glue. Using German technology, the transducer is pasted inside the vibration plate, and then the ultrasonic vibration plate is sealed, so as to realize the purpose of putting the ultrasonic transducer in the cleaning solution, and then provided by the
ultrasonic generator. Ultrasound power supply makes the ultrasonic transducer produce ultrasonic energy. Through the transmission of water, cavitation and impact flow are formed in the water to achieve the effect of cleaning the surface stains of the workpiece.
Characteristics of shock plate of metal plating immersion ultrasonic cleaner:
1. The workpiece is cleaned by the ultrasonic vibration plate input type, and the cleaning speed is fast.
2. The cleanliness of the workpiece is high and the cleanliness of all the workpieces is the same, which improves the efficiency of production and cleaning and saves electric energy, and the failure rate is low.
3. The cleaning effect of the workpiece is good after the cleaning of the equipment, and the deep holes, slits and concealed parts of the workpiece can also be cleaned.
4. The immersed ultrasonic vibration plate is used to clean the surface of the workpiece without damage.
4. It is safe and reliable, and saves solvents, heat energy, workplaces and manpower.
5. The process of rust prevention, phosphating, rinsing and drying can be matched before and after.
Type |
Diamention(mm) |
Frequency (Khz) |
Power(W) |
Ultrasonic Transducer |
UCE-UITP300W |
300*190*100 |
25,28,33,40,80,130 |
300 |
6 |
UCE-UITP600W |
360*275*100 |
25,28,33,40,80,130 |
600 |
12 |
UCE-UITP1000W |
450*350*100 |
25,28,33,40,80,130 |
1000 |
20 |
UCE-UITP1200W |
470*380*100 |
25,28,33,40,80,130 |
1200 |
24 |
UCE-UITP1500W |
520*450*100 |
25,28,33,40,80,130 |
1500 |
30 |
UCE-UITP1800W |
560*450*100 |
25,28,33,40,80,130 |
1800 |
36 |
UCE-UITP2000W |
650*450*100 |
25,28,33,40,80,130 |
2000 |
40 |
UCE-UITP2400W |
740*520*100 |
25,28,33,40,80,130 |
2400 |
48 |
UCE-UITP3000W |
820*540*100 |
25,28,33,40,80,130 |
3000 |
60 |
UCE-UITP5000W |
1200*590*100 |
25,28,33,40,80,130 |
5000 |
100 |
OEM Ultrasonic Immersible Transducer Pack(Size, Frequency,Power) |
