Industrial Ultrasonic Cleaner transducer for parts cleaner

2019-05-31 12:00 admin
Industrial Ultrasonic Cleaner transducer for parts cleaner
ultrasonic transducer is a device that converts high-frequency electric energy into mechanical vibration. The high-frequency electric energy input by the ultrasonic generator matches the piezoelectric ceramic plate with the resonant frequency of the ultrasonic transducer. The piezoelectric effect of the material transforms the electric energy into mechanical vibration, that is, ultrasonic vibration, which is transmitted to the water medium through the ultrasonic transducer, forming negative pressure bubbles and shock in the water. Wave, and in the tax-based solution transmission, to achieve the effect of cleaning the surface of the workpiece stains. The transducer is mainly composed of aluminium block, piezoelectric ceramic plate and insulating layer.
Type Length(mm) Weight(g) Frequency(KHz) Resonance Impedance
(Ω)
Static Capacity
(pF)±10%
Input Power(W)
UCE-UT-20100
PZT-8

94

900

20

10-20

5200

100

UCE-UT-25100
PZT-4
77

710

25

10-20

6600

100

UCE-UT-28120
PZT-4
66

720

28

10-20

7800

120

UCE-UT-28100
PZT-8
66

625

28

10-20

5200

100

UCE-UT-28100
PZT-4
66

624

28

10-20

6600

100

UCE-UT-30100
PZT-8
61

555

30

10-20

5200

100

UCE-UT-2560
PZT-4
77

530

25

10-20

5400

60

UCE-UT-2860
PZT-8
68

470

28

10-20

3800

60

UCE-UT-2850
PZT-4
82

425

28

10-20

4100

50

UCE-UT-3360
PZT-8
58

420

33

10-20

3800

60

UCE-UT-4060
PZT-8
55

300

40

10-20

3800

60

UCE-UT-4060
PZT-4
56

310

40

10-20

5400

60

UCE-UT-4050
PZT-4
54

260

40

10-20

4100

50

UCE-UT-4050-1
PZT-4
57

300

40

10-20

4100

50

UCE-UT-5435
PZT-4
36

135

54

10-20

3200

35

UCE-UT-6860
PZT-8
80

460

68

10-20

3800

60

UCE-UT-68120
PZT-4
67

588

68

10-20

7800

120

UCE-UT-8060
PZT-4
60

325

80

10-20

5400

60

UCE-UT-12060
PZT-4
56

260

120

10-20

5400

60

UCE-UT-13550
PZT-4
54

215

135

10-20

4200

50
Industrial Ultrasonic Cleaner transducer for parts cleaner

Industrial Ultrasonic Cleaner transducer for parts cleaner
