ultrasonic cleaner plastic parts with heating 28khz/40khz

2019-08-27 22:42 admin
ultrasonic cleaner plastic parts with heating 28khz/40khz
Product introduction
The principle of the ultrasonic cleaning machine is mainly to convert the sound energy of the power ultrasonic frequency source into mechanical vibration through transducer. The cleaning liquid in the tank is radiated by the ultrasonic wave through cleaning the tank wall, so that the micro-bubbles in the liquid in the tank can keep vibration under the action of acoustic wave. When the sound pressure or intensity reaches a certain level, the bubbles expand rapidly and then close suddenly. In this process, the bubble closes instantaneously and produces shock wave, which repeatedly impacts the adsorbent and dirt on the surface of cleaning parts. It destroys the adsorption of dirt on the surface of cleaning parts and causes the fatigue damage of the dirt layer and is rejected. Thus, the purpose of cleaning is achieved.
Product Application
Ultrasound cleaning is considered by the international community as the most efficient and effective cleaning method, and its cleaning efficiency reaches more than 98%.
Examples of applications: electronics and electrical industry machinery, automobile, motorcycle industry, chemical fiber industry, brewing industry, aircraft industry, machinery industry, broadcasting, power, communication industry, hospital, medical research industry, financial institutions, metal products industry and other application fields.
Type Internal size
L*W*H (mm)
Frequency (Khz) Power(W) Heating(W)
UCE-1006ST 280×210×210 20,28,33,40,80,130 300 1000
UCE-1012ST 400×310×280 20,28,33,40,80,130 600 3000
UCE-1018ST 490×360×320 20,28,33,40,80,130 900 3000
UCE-1024ST 630×430×320 20,28,33,40,80,130 1200 4000
UCE-1030ST 630×530×320 20,28,33,40,80,130 1500 4000
UCE-1036ST 680×530×360 20,28,33,40,80,130 1800 5000
UCE-1040ST 680×570×400 20,28,33,40,80,130 2000 5000
UCE-1041ST 730×570×450 20,28,33,40,80,130 2400 6000
UCE-1042ST 790×670×510 20,28,33,40,80,130 3000 6000
UCE-1043ST 850×770×570 20,28,33,40,80,130 4000 7000
UCE-1044ST 910×820×620 20,28,33,40,80,130 5000 7000
UCE-1045ST 960×870×680 20,28,33,40,80,130 8000 8000
UCE-1046ST 1100×930×730 20,28,33,40,80,130 10000 8000
ultrasonic cleaner plastic parts with heating 28khz/40khz

ultrasonic cleaner plastic parts with heating 28khz/40khz
