40khz ultrasonic transducer generator for cleaning

2019-05-21 10:37 admin
40khz ultrasonic transducer generator for cleaning
The oscillating signal with frequency higher than 20 KH is amplified by an ultrasonic generator, and the sound radiation through a clear medium is amplified by vibration. Cavitation effect occurs when the molecule of cleaning fluid vibrates and produces numerous tiny bubbles and generates thousands of atmospheric pressure on the surface of the object. The dirt attached to the surface is automatically peeled off. All-round cleaning without dead angle is incomparable with other cleaning methods. And do not destroy the workpiece surface.

Our company's ultrasonic generator features:

(1) It has timing function, which can achieve timing function for ultrasonic cleaning for 60 minutes;
(2) It has the function of sweeping frequency to realize sweeping frequency cleaning.
(3) Digital display of ultrasonic frequency or output power, more specific and intuitive, convenient to observe and record data;
(4) It has the functions of over-voltage, over-current and over-heat protection to prevent tube burning and reduce generator damage;
(5) The output effective power is over 98%.
(6) Important components are all imported electronic components.
(7) External PLC control switch, remote control can be added.
(8) The power and frequency of ultrasonic wave can be continuously adjusted.
(9) Full touch buttons, humanized design;
(10) Constant power output stabilization technology, constant output power is not affected by load, protect equipment.

Type

Power（W）

Frequency (KHz)

Transducer numbers

Size

AC110V60HZ+/-10%  USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

UCE-NT300

300W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

3-6

300x360x150

UCE-NT600

600W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

6-12

300x360x150

UCE-NT900

900W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

9-18

300x360x150

UCE-NT1000

1000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

10-20

300x360x150

UCE-NT1200

1200W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

12-24

300x360x150

UCE-NT1500

1500W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

15-30

300x360x150

UCE-NT1800

1800W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

18-36

300x360x150

UCE-NT2000

2000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

20-40

300x360x150

UCE-NT2400

2400W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

24-48

300x360x150

UCE-NT3000

3000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

50-60

300x360x150

High Frequency

300W-1200W

65-80khz

High Frequency

300W-1200W

120-135khz
