ultrasonic generator variable frequency for cleaning

2019-05-21 10:48 admin

ultrasonic generator variable frequency for cleaning

Supporting equipment: ultrasonic cleaning machine, ultrasonic vibration plate, ultrasonic dishwasher, ultrasonic vibration screen, ultrasonic vibration rod, all equipment of ultrasonic cleaning industry.

Scope of application: all kinds of hardware, stainless steel products, ceramic sanitary ware, optical fiber ceramics, optical lenses, mobile phone glass lenses, electroplating factory cleaning, dishwash, precision hardware, LED industry, abrasives, engines, bearings, chemical extraction, extraction, stirring and so on.

Ultrasound generator function:

1. It has short circuit protection function.

2. Over-current and over-voltage protection, in addition to setting protective current during shunting, and setting working protective current to prevent machine damage caused by excessive current or unstable voltage

3. Fully enclosed design of chassis, with anti-corrosion function of circuit;

4. Increase the protection function of head shedding.

5. Unique over-temperature protection function, over 65 degrees automatically shut down and rest, to prevent damage to the motherboard temperature is too high.

6. The output effective power is over 98%.

7. Important components are all imported electronic components.

Type	Power（W）	Frequency (KHz)	Transducer numbers	Size
AC110V60HZ+/-10% USA /LATIN AMERICA STANDARD ARE AVAILABLE AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE All of machine are available for opening remote control function to connect with your own PLC system
UCE-NT300	300W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	3-6	300x360x150
UCE-NT600	600W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	6-12	300x360x150
UCE-NT900	900W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	9-18	300x360x150
UCE-NT1000	1000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	10-20	300x360x150
UCE-NT1200	1200W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	12-24	300x360x150
UCE-NT1500	1500W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	15-30	300x360x150
UCE-NT1800	1800W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	18-36	300x360x150
UCE-NT2000	2000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	20-40	300x360x150
UCE-NT2400	2400W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	24-48	300x360x150
UCE-NT3000	3000W	20khz,25khz,28khz,33khz,40khz Frequency is adjustable	50-60	300x360x150
High Frequency	300W-1200W	65-80khz
High Frequency	300W-1200W	120-135khz
