A digital ultrasonic generator includes a rectifier filter circuit, an inverter circuit, a matching circuit and a transducer connected sequentially, and an oscillating and driving circuit that outputs control signals to the power switch tube in the inverting circuit. The inverting circuit is a half-bridge inverting circuit. The characteristics include: a control unit, which forms a control unit with one control unit. An automatic frequency tracking system based on single-chip microprocessor uses frequency conversion search method to keep the current of the input half-bridge inverting circuit at the maximum value so as to ensure that the transducer always works in the resonant state; detects the current of the input rectifier filter circuit and outputs the current detection circuit of the current detection signal to the control unit; and tracks the frequency of the control unit. The output end of the signal is connected and a first digital potentiometer which outputs a frequency regulating signal to the oscillating and driving circuit; and an input key connected with the control unit.

Type

Power（W）

Frequency (KHz)

Transducer numbers

Size

AC110V60HZ+/-10%  USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

UCE-NT300

300W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

3-6

300x360x150

UCE-NT600

600W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

6-12

300x360x150

UCE-NT900

900W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

9-18

300x360x150

UCE-NT1000

1000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

10-20

300x360x150

UCE-NT1200

1200W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

12-24

300x360x150

UCE-NT1500

1500W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

15-30

300x360x150

UCE-NT1800

1800W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

18-36

300x360x150

UCE-NT2000

2000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

20-40

300x360x150

UCE-NT2400

2400W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

24-48

300x360x150

UCE-NT3000

3000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

50-60

300x360x150

High Frequency

300W-1200W

65-80khz

High Frequency

300W-1200W

120-135khz
