Rectangle piezoelectric ceramic

Rectangle piezoelectric ceramic

Spec	Dimension (mm)	Frequency (KHz)	Capacitance (pf)	Dielectric loss tgδ(%)	Piezoelectric voltage coefficient d33	Courier temperature (℃)
UCE-25405	25×4×0.5	58	5800	≤2.0	550×	180
UCE-40405	40×4×0.5	38	7900	≤2.0	550×	180
UCE-25405	25×4×0.5	58	4800	≤2.0	400×	260
UCE-40405	40×4×0.5	38	6500	≤2.0	400×	260
UCE-25405	25×4×0.5	58	3100	≤2.0	280×	350
UCE-40405	40×4×0.5	38	5500	≤2.0	280×	350

Piezoelectric Ceramic for Tooth-cleaning

Piezoelectric Ceramic for Tooth-cleaning

Piezoelectric Ceramic for Tooth-cleaning

Rectangle piezoelectric ceramic
