Ultrasonic Cleaner power supply 40khz/28khz

2019-05-22 13:43 admin
Ultrasonic Cleaner power supply 40khz/28khz
Aiming at the need of the gradual development of the ultrasonic cleaner, through the efforts of R&D department, the ultrasonic cleaner generator is grandly introduced. It is an ultrasonic generator based on the ordinary ultrasonic generator. Through upgrading the control program, it adds automatic scanning function, analysis system, evaluation system, special regulating overcurrent protection function and working overcurrent protection function. In addition to the ultrasonic generator, there are three advantages:

1. Cleaning efficiency is high. The actual power of ordinary ultrasonic generator, such as 60W transducer, is about 70% of the rated power. With the influence of some sticking technology and glue, the actual output power is less than 60%. The effect of ultrasound is very weak, even without ultrasound. Our company's newly developed intelligent ultrasonic generator, the actual output power as high as 93%, high efficiency.

2. High ultrasound density. This is a very professional parameter. Many customers are easy to enter a misunderstanding that good ultrasonic ripple is good effect, in fact, that is wrong. Ultrasound is good or not. What we can see is the cleaning effect, density and uniformity. Here the density is high, only in the unit area, the same ultrasonic power, the higher the density of ultrasound, the better the effect. For example, in a square centimeter, some have 50 points of ultrasound, some have only 20 points.

3. The uniformity of ultrasonic wave is good. This is another professional parameter. Uniformity is another important parameter of cleaning workpiece cleanliness, which decides that in the cleaning process, any unit area of workpiece surface is cleaned thoroughly, instead of a very intensive centralized cleaning here, another corner can not be cleaned. This is tested by a professional tester. By comparing all the domestic brands of ultrasonic generators, the Taihe intelligent ultrasonic generator is obtained, which is the uniformity in China at present.

Type

Power(W)

Frequency (KHz)

Transducer numbers

Size

AC110V60HZ+/-10%  USA /LATIN AMERICA STANDARD ARE AVAILABLE
AC220V50HZ+/-10% EUROPE/ASIA/OCEANIA/AFRICA ARE AVAILABLE
All of machine are available for opening remote control function to connect with your own PLC system

UCE-NT300

300W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

3-6

300x360x150

UCE-NT600

600W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

6-12

300x360x150

UCE-NT900

900W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

9-18

300x360x150

UCE-NT1000

1000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

10-20

300x360x150

UCE-NT1200

1200W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

12-24

300x360x150

UCE-NT1500

1500W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

15-30

300x360x150

UCE-NT1800

1800W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

18-36

300x360x150

UCE-NT2000

2000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

20-40

300x360x150

UCE-NT2400

2400W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

24-48

300x360x150

UCE-NT3000

3000W

20khz,25khz,28khz,33khz,40khz
Frequency is adjustable

50-60

300x360x150

High Frequency

300W-1200W

65-80khz

High Frequency

300W-1200W

120-135khz
